LV ELECTRICAL SYSTEM
20
3.5 SIDE REPEATER LAMP (LH/RH)
Side Repeater Lamp on ORVM
REMOVAL AND REFITMENT
Please refer Body Section for removal and
refitment of side repeater lamp on ORVM.
3
.6 ROOF LAMP
Option I
Option II
Interior roof lighting lamp is provided on the roof
with inbuilt switch. The switch has three positions:
ON
The lamp will turn ‘ON’ as
long as the switch is in this
position.
DOOR
In this position, the lamp
turns ‘ON’ with dim-Ming
when either of the doors
are opened. When the last
door is closed, the lamp will
turn ‘OFF’ with dimming.
When the key is turned to
the ‘IGN’ position, the lamp
goes ‘OFF’ immediately
OFF
In this position, the lamp
will remain ‘OFF’.
