KRYOTEC ENGINE

72

vi. AC COMPRESSOR, ALTERNATOR BELT

REPLACEMENT

REMOVAL

1. Lift the vehicle and remove the RH side front

wheel.

(For procedure refer wheel section).

2. Remove the RH front wheel arch.

(For

procedure refer Body section).

3. Loosen the belt tensioner by rotating bolt in

anticlockwise direction and lock using special

tool

(5412 5890 0605)

.

4. Remove the auxiliary belt.

FITMENT

Follow the removal procedure in reverse.
