595 / 745
BODY
22
1.4.8 REAR BUMPER
REMOVAL
1. Open the tail gate.
2. Remove clip push button of front cladding,
fender.
3. Pull out the cladding fender.
4. Remove screw from the bumper and pull out
the tow ball cover, rear bumper
5. Remove the two crew from the bumper
6. Remove rear Lamp (For procedure refer Rear
Lamp removal process in Electrical section.)
7. Remove the mounting bolts from rear bumper.
