DRIVESHAFT (AT)
18
B. RH DRIVE SHAFT REMOVAL
1. Lift the vehicle on using two post lift and
remove the front wheels.
2. Remove the mounting bolts and take out the
engine guard underbody.
3. Lower the vehicle on two post lift. Remove
wheel Cap.
4. Remove wheel nut & take out wheel.
5. Remove ARB link with wheel speed sensor
bracket from front strut.
6. Remove driveshaft nut & spacer.
NOTE
Do not use air tools to remove the nut. Failure to
follow this instruction may result in damage to the
component. Discard the nut after removal.
To restrict rotation of driveshaft apply Brake.
7. Remove Tie Rod ball joint nut & spacer from
knuckle RH sides.
