6F33 TRANSAXLE
42
13.Remove all 4 bolts of shifter Housing fastened to
cabin floor.
NOTE
Smoothly remove the solenoid wire connection
from shifter housing connector.
14.Take out shifting Mechanism unit from vehicle.
16. ASSEMBLY GEARSHIFT MECHANISM
1. Follow the reverse procedure of gearshift
housing removal process.
NOTE
Tightening torque of Gear shifter housing- Hex bolt
M8x28 as 2.1-2.5 Kgfm.
2. Before assembly of console assy, Fix C Nut ST
4.8 (2 Nos) on Gear shifter Housing from TOP.
3. Ensure “Neutral setting procedure” gets
followed during reassembly.
