C635 TRANSAXLE
46
18.INPUT SHAFT DISASSEMBLY
1. Remove the
right hand thread
rear bearing
retention bolt and discard.
2. Remove the snap ring from the input shaft.
3. Remove the front bearing and the forth-sixth
gear using a press and. Using Old press plate
4. Remove the sleeve and the third-fifth gears
using a press and plates.
5. Remove the rear bearing using press plate
5438 5890 2602 and Drift Part No.2779 5890
3504
Press plate 5412 5890 2606
Drift Part No.2779 5890 3504
