ELECTRICAL
99
TELL TALES COLOR INDICATOR
REMARKS
DRL Lamp
Green
This symbol lights up when the ‘IGN’ is turned ‘ON’ and should
go ‘OFF’ after 4 seconds.
This symbol comes ON when the Day Time Running lamp is
‘ON’.
CNG Lamp
(PP)
Amber
This symbol lights up when the ‘IGN’ is turned ‘ON’ and goes
‘OFF’ after 4 seconds.
This symbol comes ON when CNG fuel mode is activated.
AMT Fault
Indicatior
Amber
When ignition is turned ‘ON’, this symbol comes ‘ON’ for four
seconds and goes ‘OFF’ after 4 seconds.
This symbol will continue to remain 'ON' after Ignition On
precheck if there is a problem in the AMT system.
Get the problem attended to at TATA authorized Service
center.
City Lamp
Blue
This symbol lights up when the ‘IGN’ is turned ‘ON’ and should go
‘OFF’ after 4 seconds.
CITY symbol ON indicates City drive mode. This mode is
used to achieve optimum torque with fuel economy.
ECO Lamp
Green
When ignition is turned ‘ON’, this symbol comes ‘ON’ for 4
seconds and goes ‘OFF’.
ECO symbol ON indicates Economy drive. This mode is used
to achieve better fuel economy.
SPORT
Lamp
Amber
This symbol lights up when the ‘IGN’ is turned ‘ON’ and goes
‘OFF’ after 4 seconds.
SPORT symbol ON indicates Sport drive mode. This mode is
used to achieve maximum torque.
Press Brake /
Clutch (Used
in
PEPS
Vehicles
)
Amber
This symbol lights up when the ‘IGN’ is turned ‘ON’ and
remains ON until user press clutch / brake to start the engine.
This symbol is turns OFF when vehicle is in Cranking /
Running Mode.
Key
Not
Detected
(Used
in
PEPS
Vehicles)
Amber
This symbol lights up when the Valid UID (User Identification
Device) is not detected inside the vehicle.
Cruise
Control
Greeen
When ignition is turned ‘ON’, this symbol comes ‘ON’ for 4
seconds and goes ‘OFF’.
This symbol comes on when the cruise function is activated in
the vehicle.
