ELECTRICAL
102
24.4 MAIN CONNECTOR PIN-OUTS
FOR 32 PIN CONNECTOR
SR.
NO
DESCRIPTION
TYPE OF
INPUT
INPUT
/OUTPUT
HIGH/ LOW
SHORT TO
BATTERY / SHORT
TO GROUND
1
Battery +VE
Power
Power
NA
2
Battery Charging
Digital
Input
Low
3
PWM OUTPUT (LSD)
PWM
Output
Low
4
Reverse Gear
Digital
Input
High
5
Can Low (Vehicle)
SIGNAL
NA
NA
X
6
Can High (Vehicle)
SIGNAL
NA
NA
X
7
Wake up input
Digital
Input
High
8
Brake fluid
Digital
Input
Low
9
Common IP Dimming (LSD) (PP)
PWM
Output
Low
10
Fuel Sender Ground
Ground
Ground
Ground
NA
11
Fuel Level Sender Input
Analog
Input
NA
12
High Beam
Digital
Input
Low
13
ECO LED ON output (LSD) (PP)
Digital
Output
Low
14
Can LOW (Diagnostic)
SIGNAL
NA
NA
X
15
Can HIGH (Diagnostic)
SIGNAL
NA
NA
X
16
Lin Package Protected
SIGNAL
NA
NA
17
SPORT LED OUTPUT LSD (PP)
Digital
Output
Low
18
PWM Output (HSD) (PP)
PWM
Output
High
19
PWM input (PP)
PWM
Input
Low
20
Immobilizer
Digital
Input
Low
21
Spare DIGITAL
Digital
Input
High/Low
22
Ignition +VE
Digital
Input
High
23
Oil Pressure
Digital
Input
Low
24
Ground
Ground
Ground
Ground
NA
25
PWM Output HSD (PP)
PWM
Output
High
26
Park Brake
Ground
Input
Low
27
Digital Spare Input
Ground
Input
High/low
28
Analog input (PP)
Analog
Input
NA
29
Outside Air Temperature
Analog
Input
NA
30
Seat Belt
Digital
Input
Low
31
OAT Ground
Ground
Ground
Ground
NA
32
PWM Output (LSD)
PWM
Output
Low
