614 / 1003
STEERING
10
2. STEERING COLUMN REMOVAL
1. Disconnect the connection of battery.
2. Remove steering wheel (
Refer Steering wheel
removal procedure).
3. Remove 2 number of screws of nacelle bottom
cover & take out the nacelle bottom cover.
4. Remove combination switch.
(Refer Electrical
section.)
5. Remove the dashboard bottom cover (
Refer
body section
).
6. Disconnect the electrical connection of EPAS
ECU.
7. Remove the 2 nos mounting nuts.
8. Remove Steering Column Pivot mounting bolt.
9. Remove the mounting screw of upper universal
joint.
