TRANSAXLE TA6300
52
7. Pull out the plunger from transaxle cable and
remove it from the transaxle cable-anchoring
bracket.
8. Loosen the cable grommet nut mounting from
firewall to remove the assembly.
ASSEMBLY:
1. Refit the selector shifter cable over the
transaxle bell crank lever and assembly
selector shifter shaft end
2. Pull and hold the plunger of the transaxle
cable. Then snap fit the cables over the
transaxle cable-anchoring bracket.
3. Insert the cable through the firewall and
tighten its mounting on it.
4. Position and tighten the assembly gearshift
housing on the cab floor.
5. Refit the selector and shifter cable lock on the
assembly gear shift housing.
6. Fix the selector cable on the assembly gear
shifter housing and leave the yellow clip
partially open.
