1.2L REVOTRON ENGINE
32
Turbocharger, Catcon and Components
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Catcon Assy
2 Hex FL screw M8x20 (4 Qty)
2.5
3 Hex FL nut am8
2.0 + 0.3
4 Turbocharger Assy
5 Gasket, Turbocharger Intake
6 Gasket, Turbocharger Outlet
7 Hex Flange Screw M6x18
2.0
8 Hex Flange Screw M6x12
2.0
10 Hex Nut M6 (2 Qty)
1.0
11 Assy. Vacuum Modulator
12 Hose Assy, EVRV To NRV
13 Bracket - NRV Mounting
14 Hex Flange Screw M6x10
15 Hose (Vacuum Line T Connector To NRV)
16 Hose, EVRV To Turbocharger
17 Hose, EVRV Vent To Air Filter
18
One Way Check Valve (NRV For Vacuum
Accumulator & EVRV Circuit)
19 Hex Flange Screw M8x18
2.0
20 EVRV Bracket
21 Heat shield rear heat shield
22 Heat shield Front
23 Washer A6.4
24 Hex FL screw M6x18
1.0
25 Hex FL screw M6x12
1.0
26 Hex Flange Nut AM8 (4 Qty)
3.0
27 Lambda sensor
5.0 ± 1.0
28 Oxygen sensor (Lambda sensor)
5.0 ± 1.0
29 EVRV Hose Separator
