1.2L REVOTRON ENGINE
38
Water Pump, Thermostat and Components
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TOQUE
(Kgf.m)
1 Water Pump Assy.
2 Water Bypass Tube Assembly
3 Seal (Water Bypass Tube)
4 Hex Flange Bolt M8x55 (2 Qty)
2.5
5 Hex Flange Bolt M8x100 (2 Qty)
2.5
6 Tube Assy, TC coolant intake
7 Sealing Washer 12x15.5
8 Pipe Union bolt 8 M12x1.5
2.5
9 Tube Assy, TC coolant intake
10 Spring band clamp 23dx12w
11 Hose, Thermostat to bypass pipe
12 Thermostat Housing
13 Bright washer 6.4
2.5
14 Hex Flange Nut AM6 (3 Qty)
1.0
15 Tube assembly, oil cooler coolant return
16 Sealing Washer 14x18
17 Pipe union bolt 10 M14x1.5
2.5
18 Adapter (water bypass)
19 Tube Assy. Oil cooler coolant inlet
