1.5L REVOTORQ BS VI ENGINE
116
F. TURBOCHARGER
REMOVAL
AND
REFITMENT
REMOVAL
1. Remove the air filter mounting bolts and pull
in outward direction to dislocate the filter
assembly from the locating bush on the rear
side. The air filter assembly will be come out
along with the dampener.
2. Disconnect the electrical connections.
3. Disconnect and set the intercooler hose to
turbocharger aside.
4. Disconnect and set the oil separator hose
aside.
5. Remove turbocharger compressor inlet hose.
