BODY
35
2.23 FRONT ROW SEAT
REMOVAL
1. Slide the Front seat backwards and remove
the two front mounting screw.
2. Slide the Front seat at front and remove the
rear mounting screw.
3. Detach seat belt buckle reminder sensor from
vehicle wiring harness.
4. Push Front Seat at Front.
5. Remove front Seat.
FITMENT
1. Locate the front seat assembly in BIW using
Locating Pin.
2. Fix the seat assembly at front by tightening two
mounting screws.
3. Slide the front seat forward most position.
4. Connect seat belt buckle reminder sensor to
the vehicle wiring harness.
5. Fix the seat assembly at rear by tightening
three mounting screws.
