1.2L REVOTRON ENGINE
106
K. WATER PUMP
REMOVAL
1. Drain coolant.
2. Remove auxiliary belt.
3. Disconnect hose connecting water bypass
tube.
4. Pry out engine wiring harness mounting on the
support bracket.
5. Remove mounting bolts of the water bypass
tube.
6. Disconnect the water bypass tube from water
pump.
7. Remove mounting bolts and take out water
pump.
FITMENT
For fitment follow the reverse order of removal.
