FATC
16
9. AUTO ON SELECTION BUTTON
In the AUTO mode all the configurable parameters
will be selected automatically except temperature
selection
To put the automatic climate control in fully
automatic mode:
a. Set the desired temperature by turning
temperature control knob.
b. Press the ‘AUTO’ button.
c. The system automatically selects the propermix of
conditioned and/or heated air that will, as quickly
as possible, raise or lowers the interior
temperature to your preference.
You can manually select various functions of the
climate control system when it is in fully automatic
10. TEMPRETURE SELECTION
Rotate the Knob to clockwise & anticlockwise
direction to control the temperature. Turning the
temperature control knob clockwise increases the
temperature of the air. Steps of 0.5 º C. will increase
the desired temperature. User can select
temperature range from 18ºC to 30ºC. Whereas the
anti-clockwise direction decreases. The desired
temperature selected by the user shall be updated in
the display simultaneously as per the rotation of the
knob.
When you set the temperature to its lower limit (Lo)
or its upper limit (Hi), the system performs to provide
full cooling or heating respectively.
