ALTROZ SERVICE MANUAL

FATC

4. BLOWER SPEED CONTROL DOWN BUTTON

Press the knob to reduce the speed up to Min (Speed

1).Blower control shall indicate the control of the

quantity of airflow, which is accomplished by

controlling the speed of the blower fan. The Blower

control shall happen either manually or through an

automatic climate control algorithm

5. BLOWER SPEED CONTROL UP BUTTON

Press the knob to increase the speed up to Max.

Blower control shall indicate the control of the quantity

of airflow, which is accomplished by controlling the

speed of the blower fan. The Blower control shall

happen either manually or through an automatic

6. AC COMPRESSOR ON / OFF BUTTON

Press the AC compressor ON/OFF button to turn

the air conditioning ON or OFF.

7. FRESH AIR / RECIRCULATION BUTTON

a. When the user pushes the Fresh air \ Recirculation

button , the LED turns ON, the air inlet door flap

shall move to the RECIRCULATION position and

air from the vehicle’s interior is sent throughout the

system.

b. When the user pushes the Fresh \ Recirculation

button and the LED turns off, air is brought in from

outside of the vehicle (fresh mode). Whenever

discomfort is felt, switch to fresh air mode.

c. The Fresh \ Recirculation control shall switch to

Auto operation immediately after the user presses

the Auto button. The Climate control algorithm

shall calculate the status of the Fresh \

Recirculation door flap. The LED shall not indicate

the status of the door flap during Auto operation.

NOTE

1. The outside air intakes for the climate control

system are at the base of windscreen. Keep this

area clear from leaves and other debris.

2. The system should be used with recirculation

air mode for faster heat up and cool down,

however keeping the system in recirculation

mode, particularly with AC OFF, can cause the

windows fog up.

CAUTIONS

It is recommended to run the vehicle in re circulation

mode to avoid clogging of air filter.

8. “OFF” BUTTON”

Press the OFF button to switch OFF the system.

The display will no longer show the climate control

option when panel is OFF.
