ELECTRICAL
51
REMOVAL (Level A)
1. Carefully pry out fascia switch cover assembly.
2. Remove the 4 mounting screw on Display
Unit.
3. Disconnect all the electrical connections on
Display unit and take it out.
4. Disconnect all the electrical connections on
Infotainment silver box unit
5. Remove the 2 mounting screws on
Infotainment silver box unit.
6. Take out Infotainment silver box unit.
REFITMENT
For refitment follow the procedure in reverse.
