FRONT & REAR BUMPER
1
A. FRONT BUMPER REMOVAL (TIGOR)
1. Open the bonnet.
2. Remove BOLT and clip button on Front
Bumper.
3. Remove on screws Front Bumper from LH
and RH side.
4. Remove H/FL BOLT and screws from bottom
side of Bumper.
5. Remove two screws on liner wheel arch front.
6. Pry out three clips and keep Front Fender
cladding in hanging position from RH and LH
side.
7. Remove Fog Lamp connection (If Applicable)
