GEARBOX
7
18. Pull out Knuckle Assembly and Swing out
both drive shafts from transaxle and place it
suitably alongside.
Do not pull drive shaft excessively as the
plunge joint will come out of housing and
damage the boot Pry. Plunge joint housing for
taking out joint out of splines. Do not place the
CV drive shaft on rough / uncleaned surfaces.
This might damage the drive shaft boot.
19. Remove Starter Motor.
20. Lower the car & give support to the gear box
from Bottom side.
21. Remove B-Mount Nut & Loosen B Mounting
stud as shown
22. Uplift the car & give support to the Gear Box
from bottom side.
23. Remove gear box Housing mounting bolts on
Engine from top side.
24. Remove gear box Housing mounting bolts on
Engine from Bottom side.
25. Remove C-Mount Bracket mounting bolt
26. Lower Gear Box with AMT KIT using Device.
FITMENT:
For fitment follow the reverse procedure of
removal.
