GEARBOX
3
18. Remove Mounting on Wheel speed sensor
and disconnect it.
19. Disconnect Transmission earthing cable from
Gear Box.
20. Drain the Transaxle oil from Drain plug
21. Pull out Knuckle Assembly and Swing out
both drive shafts from transaxle and place it
suitably alongside.
Do not pull drive shaft excessively as the
plunge joint will come out of housing and
damage the boot Pry. Plunge joint housing for
taking out joint out of splines. Do not place the
CV drive shaft on rough / uncleaned surfaces.
This might damage the drive shaft boot.
22. Disconnect electrical connection on starter
motor.
23. Remove Starter Motor.
24. Lower the car.
25. Remove B-Mount Nut & Loosen B Mounting
stud as shown
