ELECTRICAL
83
REMOVAL& INSTALLATION
REMOVAL
1. Remove window-winding switch from door pull
outer.
1. Remove the switch assembly from bezel and
disconnect the electrical connector & take out
the switch assy.
Same procedures are to be followed for co-drivers
and passengers window module switches
INSTALLATION
1. Connect the electrical connector of switch.
2. Position the switch onto the bezel and push fit
the assembly.
NOTE:
Follow the same procedure to remove
remaining door window winding switches.
REMOVAL& INSTALLATION
REMOVAL
1. Pull out window-winding switch Bezel from
front driver door.
2. Remove the switch assembly from bezel and
disconnect the electrical connector & take out
the switch assy.
Same procedures are to be followed for co-drivers
and passengers window module switches.
INSTALLATION
1. Connect the electrical connector of switch.
2. Position the switch onto the bezel and push fit
the assembly.
NOTE:
Follow the same procedure to remove
remaining door window winding switches.
