ELECTRICAL
71
21.5 ANTENNA (If Applicable)
The antenna designed to effectively capture
radiated RF signals in the AM and FM bands.
LOCATION:
Antenna is located on the roof, above the Back
windshield glass.
REMOVAL:
1. Pull out the roof console bezel cover .
2. Remove the screw of housing console.
3. Disconnect the electrical connection.
4. Remove the fixing screw and take out the
antenna from the top.
REFITMENT
For refitment follow the procedure in reverse.
Torque specified for fixing screw: 5 Nm±1
