1.2L REVOTRON ENGINE
118
9. Remove fixed guide rail.
10. Remove the Timing chain from the gear train
assembly.
11. Remove the VCT and exhaust camshaft
sprocket.
12. Remove the crankshaft sprocket by removing
key.
13. Remove the crankshaft gear by removing the
pin.
14. Lock the balancer shaft in the bedplate using
a locking bolt
(5715 0310 9904)
as shown
below.
