KRYOTEC ENGINE
90
19.Remove mounting screws and take out water
housing elbow assembly.
NOTE
Gasket not to be reused.
20.Remove exhaust manifold mounting fasteners
and take out the assembly.
NOTE
Fasteners not to be reused.
21.Remove exhaust manifold gasket.
NOTE
Gasket not to be reused.
iv. REMOVAL OF ENGINE PERIPHERALS
1. Remove mounting bolts of oil mist separator
and take out the unit.
NOTE
O-rings not to be reused.
2. Disconnect the return line to H.P. pump.
3. Remove mounting bolts and remove fuel
return manifold along with back leak hose.
