KRYOTEC ENGINE
85
21. Remove front side lifting hook.
ii. REMOVAL
OF FUEL INJECTOR AND
PERIPHERAL
1. Remove the high pressure fuel lines
connecting the fuel injectors.
NOTE
Cover the opening of the fuel rail and fuel
injectors with suitable plugs.
After removing the HP pipes cover the
injectors and fuel lines opening with suitable
caps.
Do not reuse the HP pipes once removed;
use new HP pipes at the time of assembly.
2. Pull out mounting clips and disconnect back
leak hose to the fuel injectors.
