KRYOTEC ENGINE

82

7. ENGINE OVERHAULING

A. ENGINE DIS-ASSEMBLY

i. ON OVERHAUL STAND

1. After removing the engine assembly from the

vehicle, keep that engine on engine support

stand

. (Engine Support Stand -: 5412 5890

2402).

2. Remove gear box assembly.

(Refer Gear Box

section).

3. Remove clutch assembly.

(Refer Clutch

section).

4. Loosen the tension and lock the belt tensioner

of auxiliary belt using locking pin

(5412 5890

0605).

5. Remove the auxiliary belt from the pulley.

6. Disconnect electrical connection to the

compressor.

7. Remove the mounting bolts of the support

bracket and release the compressor assembly

from the mounting bracket.
