KRYOTEC ENGINE
101
10. Remove all the upper main bearing half shell
from crankcase.
11. Remove the piston cooling nozzles.
NOTE
Gasket not to be reused.
Refer “Repair and Inspection Details” section for
Inspection details.
x. REMOVAL OF CYLINDER HEAD SUB-
ASSEMBLIES
1. Remove the roller finger follower and
hydraulic lash adjuster assemblies.
2. Using valve spring compressor remove the
valve spring retainers, valve spring and valve
spring washers.
(Handle -: 5530 5890 0101, Adapter -: 5412 5890
0606 & Support rail-: 5412 5890 0607)
NOTE
The lock halves hold the spring retainer in place
when relieving pressure applied by the spring
compressor.
3. Repeat the same procedure for all valves.
4. Remove the valve from below.
NOTE
Refer “Repair and Inspection Details” section for
Inspection details.
