FATC
19
REMOVAL
1. Pry out the sensor using suitable tools.
2. Disconnect the electrical connection of solar load
sensor.
3. Rotate the sensor in anticlockwise direction and
take it out from the holder.
REFITMENT
For refitment follow reverse procedure of removal.
B. OAT SENSOR
The ambient temperature sensor is an encapsulated
thermistor that provides the ECU with an input of
external air temperature. Ambient sensor is a ther-
mistor that decreases its resistance when
temperature increases and increases when tempera-
ture decreases.
LOCATION
Outside Ambient Temperature (OAT) sensor located
under the front grill / front bumper.
CONNECTOR DETAIL
PIN
DESCRIPTION
1
Solar sensor Input to control panel
2
Analog GND
