FATC
12
1.4. FATC CONTROL PANEL
An electronic control unit known as the control panel, which has a built in algorithm to maintain the CCM settings,
conditions set by the user, manages the climate control system automatically. The layout of the knobs and
pushbuttons on the control panel are as below.
FATC Controls
1. AC Compressor ON/OFF Button
7. AC Blower OFF Button
2. ECON (Economy Mode) Button
8. Temperature Control Knob
3. Windshield Defrost Button
9. Auto Mode
4. Rear Defogger / Demister Button
10. In-cab Sensor
5. Air Recirculation Button
11. Blower Speed Control Knob
6. Air Flow Mode Button
FATC: - FULLY AUTOMATIC TEMPERATURE
CONTROL:
GENERAL DESCRIPTION:
FATC system controls the in-cabin Temperature of
the vehicle automatically and provides maximum
passenger convenience regardless of outside
weather conditions.
! CAUTION
If the display flashes ‘ERR’ in periodic pattern (Dis-
play will show ‘ERR’ for 5 sec. and set temperature
for 30 sec.),It indicates FATC malfunctioning.
Switch over to manual mode and contact
TATA
MOTORS
authorized service station.
1. AC COMPRESSOR ON / OFF BUTTON
Press the AC compressor ON/OFF button to turn
the air conditioning ON or OFF. You will see AC
text on the display, when AC is ON.
