HARRIER BOOK-1

ELECTRICAL

103

REMOVAL& INSTALLATION

REMOVAL

1. Remove the door trims

(Refer Body Section for

removal procedure)

2. Gently pry out the switch bezel fromthefront door

by pushing the mounting clip with the

screwdriver.

3. Remove the switch assembly from bezel.

4. Disconnect the electrical connector & take out

the switch assy.

Same procedures are to be followed for co-drivers

and passengers window module switches

INSTALLATION

1. Connect the electrical connector of switch.

2. Position the switch onto the bezel and push fit

the assembly.

NOTE

Follow the same procedure to remove remaining door

window winding switches.
