ELECTRICAL
107
LOCATION
It is located on the steering wheel.
REMOVAL
1. Remove steering wheel. Refer “Removal &
Refitment of steering wheel" from Steering
Section
2. Remove the back cover of the steering wheel.
3. Remove electrical connections.
4. Take out the switches.
INSTALLATION
1. Locate the switches on the steering wheel.
2. Fit the bottom cover of steering wheel.
3. Tight the mounting screws of both the switches.
Tightening torque: 2.0 ± 0.5 Nm
4. Fit the steering wheel.
21. DOOR HANDLE SWITCH
REMOVAL& INSTALLATION
1. Disconnect the battery.
2. Remove the Door Handle.
(Refer Door Handle
Removal Procedure in the Body Section).
3. Unscrew the door handle cover with dedicated
screw panel.
4. Remove door handle switch wire harness fitted
in the handle.
