KRYOTEC ENGINE

92

10. Remove mounting screws and take out the

vacuum pump.

NOTE

Gasket not to be reused.

v. REMOVAL OF TIMING BELT

1. Remove mounting screw and remove upper

timing cover.

NOTE

Fasteners not to be reused.

2. Remove damper pulley.

3. Remove mounting screw of the bottom belt

cover. Take out the bottom belt cover.
