P0674-13: Glow plug 4 (open circuit)

Overview:

DTC Description (User Friendly)

Glow plug 4 (open circuit)

ECU Pin Number

Glow Plug Module Pin Number

G4 (in 4 pole connector)

Customer Symptom

No Symptoms, Glow Plug Lamp ON, Under Cold climates

(below 0 degrees C), Prolonged cranking of Engine happens.

Fault Effects (On Vehicle)

Under Cold climates (below 0 degrees C), Prolonged cranking

of Engine happens

Lamp Status (If Any)

Glow Plug Lamp ON

Fault Detection Condition (Root cause)

Glow Plug Module pin G4 (in 4-pole connector) got open

circuited.

Normal Operating Condition

No Fault

Probable Trouble Area

Wiring Harness Connections between EMS ECU and GPIU

Module.

GPIU Module

EMS ECU

Healing Condition

Rectify the error

Clear through diagnostic tool

Ignition OFF & ON

Component Details:

Glow Plug Control Module controls the operation of Glow Plugs installed on each engine cylinder.

Glow Plug Module also provides feedback to EMS ECU regarding the activation status of glow plugs, failures in glow

plugs wiring connections / GPIU module itself. EMS ECU will take rectification actions, incase GPIU reports any errors.

Glow Plugs are installed on engine cylinders to warm up the engine cylinder chamber to aid the vehicle starting and

emission control under ambient temperatures below 0 degrees.

Preliminary Checks:

1. Check whether the customer voice / view about the issue is matching with the fault effects mentioned in above

Table. If yes, go ahead with next steps. If not, check for other DTC’s presence.

2. Check whether other customers report similar complaints earlier. If yes, perform the preliminary checks with

respect to earlier issue closure.\

3. Check the wiring harness connections between EMS ECU and GPIU Module as per the circuit Schematic.

4. Loose/ Damaged Connections between GPIU Module and EMS ECU.

5. Loose/ Damaged Connections between GPIU Module and Battery supply or Main relay supply.

6. Check for proper installation of GPIU Module in Vehicle.

7. Check for damage of pins at EMS ECU connector and GPIU Module connector.

Trouble Shooting:

Step Checks

IF YES

IF NO

Check Whether the GPIU Module is installed on Vehicle

Go to Next Step

Fit GPIU Module

Check for any mechanical damage in GPIU Module or

Glow Plug of cylinder 4.

Call Hotline

Go to next step
