P0404-19: EGR “A” Control Circuit Range / Performance – EGR high pressure valve control (circuit current above

threshold)

Overview:

DTC Description (User Friendly)

EGR high pressure valve control (circuit current above threshold)

ECU Pin Number

A067, A088, A040, A079, A078

Customer Symptom

MIL ON, CEL OFF. No significant symptom, slight rough idle will

be observed

Fault Effects (On Vehicle)

Slight Rough Idle

Lamp Status (If Any)

MIL ON, CEL OFF

Fault Detection Condition (Root cause)

EMS pin A067 Shorted to Ground or A088 shorted to Battery

supply

Normal Operating Condition

No fault

Probable Trouble Area

Wiring Harness connections between EGR valve and EMS ECU

EGR Valve

Engine Management System

Healing Condition

Rectify the error

Clear through diagnostic tool

Ignition OFF & ON

Component Details:

An incomplete burnt gas in exhaust is return to the cylinder. EGR works by recalculating a portion of an engine's

exhaust gas back to the engine cylinder. Intermixing the incoming air with recalculated exhaust gas dilutes the mix with

inert gas and in turn reduce the combustion temperatures for reducing NOx emissions.

Preliminary Checks:

1. Check whether the customer voice / view about the issue is matching with the fault effects mentioned in above

Table. If yes, go ahead with next steps. If not, check for other DTC’s presence.

2. Check whether other customers report similar complaints earlier. If yes, perform the preliminary checks with

respect to earlier issue closure.

3. Check for any leakages in EGR flow path.

4. Check whether the EGR valve is physically damaged.

5. Check whether the EGR valve is fouling with any other component.

6. Check for damage of pins at ECU connector.

7. Check the wiring harness connections between the EGR valve and EMS ECU.

Trouble Shooting:

Step Checks

IF YES

IF NO

Run the EGR High Pressure DC Motor Test Routine. Is the

Routine Result – OK?

Go to Next Step

Rectify the wiring

Harness

connections

between EGR

Valve and EMS

ECU. Repeat the
