If the Routine result
is negative, then
call hotline for
confirmation to
replace EGR valve.
2
Check for mechanical damage / Blockages in EGR Valve
Remove the
blockages. If found
damaged then call
hotline to confirm
EGR valve
replacement.
Go to Next Step.
3
Check for inlet air circuit clogging
Replace faulty Relay Go to next step
4
Check whether air filter is clogged
Rectify / Remove
the clogging
Go to Next Step
5
Check whether any MAF sensor related faults are logged
Rectify them by
following their
rectification
procedure
Go to Next Step
6
Check whether atmospheric pressure sensor faults are
logged.
Rectify them by
following their
rectification
procedure
Go to Next Step
7
Check the Electrical Continuity between the EGR Valve
and EMS ECU. For pin details, refer schematic section
below.
Go to next step
Rectify the wiring
harness
connections as per
the circuit
schematic.
8
Are there any pins damaged at EMS ECU Connector
Replace the
connector or wiring
harness
Go to Next Step
9
Are there any pins backed out from the EMS ECU
Connector
Rectify/Replace
Connectors
Go to Next Step
10
Check whether any of the EGR valve pins (A067, A088,
A040, A079, A078) are short circuited to Battery / Ground.
Rectify the wiring
Harness
Connections
Go to Next Step.
11 Fault Persists.
Call Hotline
Repeat the above
steps for re-
confirmation
DTC’s confirmation:
After rectification, Test Drive the vehicle for 2 KM and ensure that no DTC’s are logged in ECM.
Incase EGR valve is needed to be replaced, then open the Component Replacement Tab and execute below routines:
“EGR high pressure offset reset and activation of the learning ($ 02 0F)”
“EGR High Pressure DC Motor Test”
