Q501 4 Cylinder MT Application
DTC Troubleshooting Data
Version: 0.1
Date: 21-Sep-2018
Prepared By: Mithi Prasad, Sarang Kulkarni, Manish Gupta
Checked By: Yogesh Jadhav
Approved By: Satish Kumar P
Page: 511 of 1052
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Circuit Schematic:
Component Location & Image:-
NA
Connector View & Information: -
EMS ECU
A005
A029
A028
Swirl position sensor
and Actuator
01
06
05
02
02
O_T_VSA
I_T_VSA
G_R_VSA
To Main
Relay
