SRS / Airbag
ECU – DTC Troubleshooting Guide
Version: 14.0
Date: 14-February-2017
Prepared by:Airbag COC Review &
Approved by:Sanjeev VM
Page: 500 of 549
B0029-1B:- Right Curtain Deployment Control circuit resistance above threshold
Overview:-
ISO Code
B00291B
Customer Symptom
SRS Warning Lamp continuously ON in Instrument Cluster.
Fault Effects (On Vehicle)
Right Curtain deployment not guaranteed, if a crash happens
Lamp Status (If Any)
SRS Warning Lamp continuously ON in Instrument Cluster.
Fault Detection Condition
This fault gets logged if the circuit resistance of Right Curtain is
above the threshold value (5.5 Ohm) after 4 seconds of cranking.
Normal Operating Condition
The maximum threshold for Right Curtain Deployment Control
circuit is 5.5 Ohm.
Probable Trouble Area
Related wiring Harness, connector or terminals
Right Curtain Module
Airbag ECU
Airbag Wiring Harness
Healing Condition
Maximum threshold resistance for Right Curtain should be less
than 5.5 Ohm.
Component Details:-
Right Curtain Module
: - In the vehicle, curtain Airbag is folded and installed behind roof headliner on right side of the
vehicle.
Airbag ECU
: - It is fitted in the floor of central console in the car. The Airbag Electronic Control Unit (ECU) controls the
deployment system to allow an appropriate igniting of the Airbags and belt pre-tensioners to restrain the driver and
passengers.
Preliminary Checks:-
1. Check Battery Voltage (12 V & above)
2. Check for any faults in Airbag Warning Lamp indication in Instrument Cluster.
3. Ensure the proper locking of Airbag ECU wiring harness connectors in the vehicle by the locking sound.
Trouble Shooting:-
