{Osprey CCM}
DTC Troubleshooting Data
Version: 2.0
Date: 28-Jul-17
Author: ERC
Page: 199 of 244
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Circuit Schematic Diagram:-
S
chematic shared separately in PDF.
Component Location & Image:-
NA
Connector Location: -
Behind the FATC ECU Body.
Connector View & Information:
Inspection Method: -
Use multimeter check voltage between battery & ground pin.
+Vbat (pin 32)
GND (pin 19)
