Start response: 71 01 3e 02
Step 2 - After every 1 second read status record till the calibration takes place
Routine result: 31 03 3e 02
Routine result: 71 03 3e 02 [Routine Information -1 byte] [Response Additional Data -3 bytes]
NOTE: -
Require the routine to be executed with a pop up to the user in event of failure or success of the
routine. In case of failure\unsuccessful status of any of the motor actuators terminate with
instructions to resolve the problem i.e. A) Execute the Motor Calibration Routine through
³
Routine
test
´
tab. B) Read DTCs and debug the problem using DTC trouble shooting guideline. C) On
resolving the issue, the ECU replacement procedure should be executed again.
9. Read the DTC (write it to log) and clear the DTC.
10. Unlock security to FATC ECU (27 03/04)
11. Do the Diagnostics process
a. Read VIN from Vehicle (22 f1 90)
b. Write VIN in FATC (2E F1 90 11 11 11 11 11 22 22 22 22 22 33 33 33 33 33 44 44 00 00 00
00 00 00 00)
c. Read VIN in FATC (22 F1 90)
12. Read version no from existing FATC and compare against server
DID
DID Name as per HVAC
CM_Specific_Diag
Specification_Service
DID Name as per PLM Server
7244 ECU Parameterization Software Number FATC Parameter Part Number
4A9F FATC Cal Variant coding
HVAC CM Cal Variant coding
F195
System Supplier ECU Software Version
Number
System Supplier ECU Software Number
13. Read the below DIDs from the existing FATC: -
a. Vehicle Manufacturer ECU Software Version Number (F1 89)
b. Vehicle Manufacturer ECU Hardware Number (F192)
c. Vehicle Manufacturer ECU Hardware Version Number(F193)
d. Vehicle_Manufacturer_Spare_Part_Number (F187)
