ABS DTC Troubleshooting Data
Version: 1.0
Date: 03-Dec-15
Author: ERC, Chassis E&E CoC
Page: 99 of 154
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Trouble Shooting:
CHECK WHETHER PROBLEM
REPORTED IN EOL
CHECK ACTUATION TIMINGS
IN EOL ROUTINES
IS PROBLEM
REPORTED IN
EOL?
1. CLEAR THE DTC FROM THE MEMORY.
2. PERFORM IGNITION OFF/ON.
WAIT FOR 5 SEC.
3. DRIVE THE VEHICLE AROUND 60KMPH.
A
NO
YES
YES
START
IS DTC
PRESENT?
STOP
NO
1. CONNECT THE TML DIAGNOSTIC TOOL.
2. TURN THE IGNITION ON.
3. CHECK THE STATUS OF DTC’s (MENORIZED/CURRENT)
4. RECORD THE DTC AND CLEAR.
5. TURN IGNITION OFF & ON.
6. VERIFY IF DTC U3000-4B IS PRESENT
