3525 / 4910
Vehicle Platform: OSPREY / AMP
ECU Name: PEPS
DTC Troubleshooting Data
Version: 1.2
Date: 29 Mar 2017
Author:
Rajasekhara Reddy
Page: 243 of 369
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Trouble Shooting:-
Start
1. Keep vehicle in static condition.
2. Turn IGN ON.
3. Keep UID outside the vehicle.
4. Give Ignition cycle.
Is
Vehicle is
cranking
?
No
Check & Fix for the cut & short to Ground on
the harness between wire of connector-3 /
pin-17 and Crank relay coil pin.
Stop
Is
DTC: B1019-11
False
?
Yes
No
Clear
B1019-11
DTC only.
Replace the
PEPS ECU.
Yes
Keep Vehicle in Ignition power mode
No
