P0685 - 74: Main relay command (actuator slipping) - Actuator slipping
DTC Description as per ISO standard
Main relay command – Actuator slipping
ECU Pin Number
K88,K01,K03,K05 (supply after main relay)
Customer Symptom
Vehicle cranking not possible
Fault Effects (On Vehicle)
Vehicle may not start
Lamp Status (If Any)
-
Fault Detection Condition (Root cause)
Ignition ON
Normal Operating Condition
Fault condition no more present
Probable Trouble Area
1. Check the other DTCs
2. Main relay circuit short intermittently
3. EMS ECU.
Healing Condition
1. Run the diagnostic procedures to check the ECU Power &
ground.
2. Check Supply after main relay
3. Clear the DTC.
4. Read the DTC once again.
Component Details:
EMS ECU is an electronic controller which controls the Engine functionality by interfacing with various sensors, actuators
And other controllers (via CAN).
Preliminary Checks:
1. Check whether the customer voice / view about the issue is matching with the fault effects mentioned above.
2. If yes, go ahead with next steps. If not, check for other DTC’s presence.
3. Check whether similar complaints are earlier reported. If yes, perform the preliminary checks with respect to
4. Earlier issue closure. Check for pin back out at EMS ecu connector.
5. Check whether the EMS is receiving Battery supply and Ground
6. Check whether the Battery is healthy.
