P0134-01:O2 sensor circuit no activity detected: Lambda probe upstream Serial Peripheral Interface error
detection (generical electrical failure)
Overview:
DTC Description (User Friendly)
O2 sensor circuit no activity detectedLambda probe upstream
Serial Peripheral Interface error detection (generical electrical
failure)
ECU Pin Number
llCustomer Symptom
MIL ON, CEL OFF
Fault Effects (On Vehicle)
-
Lamp Status (If Any)
MIL ON. MIL Turns Off as and when fault condition is not
present / healed.
Fault Detection Condition (Root cause)
The error is detected if during SPI communication with the
CJ135 for sensor 1 bank 1 an error has ocurred.
This includes data transfer coming from the chip and going to
the chip. It is very difficult to simulate the error, because it
occurs between the chip and microcontroller.
Normal Operating Condition
Proper wire harness connection between EMS ECU and
lambda sensor.
Probable Trouble Area
Wiring harness connections between lambda sensor and
EMS ECU.
Healing Condition
Rectify the error Clear through diagnostic tool.
Ignition OFF & ON
Component Details:
The O2 sensor is mounted in the exhaust manifold to monitor how much unburned oxygen is in the exhaust as the
exhaust exits the engine. Monitoring oxygen levels in the exhaust is a way of gauging the fuel mixture. It monitors fuel
mixture is burning rich (less oxygen) or lean (more oxygen).
Preliminary Checks:
1. Check whether the customer voice / view about the issue is matching with the fault effects mentioned in above
Table. If yes, go ahead with next steps. If not, check for other DTC’s presence.
2. Check whether other customers report similar complaints earlier. If yes, perform the preliminary checks with
respect to earlier issue closure.
3. Check for Damage in EMS ECU connector / Lambda sensor.
4. Check for any back out of pins at EMS ECU connector / Lambda sensor.
5. Check for any damage of pins at EMS ECU connector / Lambda sensor.
