Q501 4 Cylinder MT Application
DTC Troubleshooting Data
Version: 0.1
Date: 21-Sep-2018
Prepared By: Mithi Prasad, Sarang Kulkarni, Manish Gupta
Checked By: Yogesh Jadhav
Approved By: Satish Kumar P
Page: 248 of 1052
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Trouble Shooting:
Step Checks
IF YES
IF NO
1.
Check for corresponding fault in Immobilizer unit. Rectify
the fault by following its rectification procedure. Action
Successful?
Go to next step.
Replace the
Ignition lock set
along
withimmobilizer
unit.
Pair the new keys
with Immobilizer.
DTC’s confirmation
(checks before handing over vehicle to customer)
:
After the DTC clearing, vehicle should be start & no error in immobilizer.
Immo telltale on Instrument cluster shall be off.
Circuit Schematic:
NA
Component Location & Image:-
NA
Connector View & Information: -
