Step Checks
IF YES
IF NO
1.
Give a battery reset to EMS and IMMO and give a Power
latch of 15 secs and then Turn ON ignition. Problem
resolved?
Confirm that issue
resolved and
handover vehicle
back to customer.
Go to next step
2.
Perform the Immo pairing using the diagnostic tool. Immo
pairing successful?
Go to next step
Check whether the
CAN
Communication is
healthy. If Yes,
replace Immo /
EMS and perform
theImmo pairing.
DTC’s confirmation
(checks before handing over vehicle to customer)
:
After the DTC clearing, vehicle should start, no error in immobilizer &Immo telltale off.
Circuit Schematic:
NA
Component Location & Image:-
NA
Connector View & Information: -
