B2256- 14: Wiper High/Low Relay Short to Ground/ Open

Overview:

ISO Code (DTC Code)

B2256- 14

Customer Symptom

Front Wiper is always operate in High speed mode

when user request low speed mode through combi

switch.

Fault Effects (On Vehicle)

Front Wiper will always operate in high speed mode

when requested.

Lamp Status (If Any)

Fault Detection Condition

This fault will logged with IGN ON

Normal Operating Condition

IGN ON and No DTC logged. Front wiper operated in

low speed and high speed as per switch request.

Probable Trouble Area

1. BCM connector Fault.

2. Front harness Short to Ground.

3. Relay fault.

4. ECU fault.

Healing Condition

1. Switch request after fault removal

2. Clear DTC command- No DTC logged

Component Details:

BCM drives the wiper motor in Low/ High speed through this relay(speed selection) by providing GND to the

relay coil. Hence in case this output is shorted to GND the relay will be continuously ON(If the relay is ON, it

will drive the wiper motor in Fast speed). Hence whenever User will switch ON the wiper, the wiper motor will

switch ON in fast speed mode.

Preliminary Checks:

1. Check Battery Voltage (9V-16V)

2. Check ECU pins for oxidation, bending & damage.

Trouble Shooting:-
