Trouble Shooting:
Step Checks
IF YES
IF NO
1.
Read the Fault in ECU
2.
Read IMA code in ECU for injector 3
Go to step 3
Go to step 5
3.
Compare the IMA code written and IMA code on sticker
4
IMA code written in ECU not correct
Go to Step 5
5
Write correct IMA code in ECU memory
Go to Step 6
6
Clear the DTC and read again
DTC’s confirmation:
After rectification, Test Drive the vehicle for 2 KM and ensure that no DTC’s are logged in ECM.
Circuit Schematic:
Not Applicable
Component Location & Image:-
Not Applicable
Connector View & Information: -
Not Applicable
