P0604 - 00:- Internal Control Module Random Access Memory (RAM) Error
Overview:
ISO Code
P0604 - 00
Customer Symptom
BCM will probably not function or will function
intermittently or partially
Fault Effects (On Vehicle)
N/A
Lamp Status (If Any)
None
Fault Detection Condition
Fault logged in the event of RAM error
Normal Operating Condition
Normal operating range:
ECU will be awake from 6V to 16 V.
Full assistance is b/w 11.5 to 16 volts.
Reduced assistance is b/w 9 to 11.5 V
Probable Trouble Area
BCM internal damage
Healing Condition
N/A
Component Details:
N/A
Preliminary Checks:
1. Voltage at the battery terminals should be greater than 11.5V.
2. BCM power supply connector should have greater than 11.5V for full assistance.
3. Check battery cable and BCM connector terminals for damage.
4. Check BCM ECU for pin bend/damage.
5. Alternator output voltage should be between 13.5 V to 14.5 V in engine running condition.
