Trouble Shooting:-
DTC’s confirmation:-
Start
Read IVN DTCs in BCM
If MTO logged against
BCM in current state?
No (In history)
Check continuity between BCM CAN_H (Connector A pin no. 48 ) to
VICM CAN_H(Pin no.3 ) and BCM CAN_L (Connector A pin no. 49 )
to VICM CAN_L( pin no.8 ) in vehicle wiring side connector.
Is continuity
there?
Repair the wiring harness
Clear DTC
Stop
Check Ignition ( pin no. 4,battery(pin no.1,7.) and
Ground (Connector pin no. 2) of VICM is properly
connected or not. Also check fuse blown (fuse-5A )
Do necessary repair in the harness
Yes
Yes
No
U0167-08 Loss of communication with Vehicle Immobilizer
Control Module- VICM Message Time Out Failure
